Datavideo NVS-40 négycsatornás video encoder és felvevő

Video Input

HDMI x4
(Channel 1 SDI/HDMI selectable)

Supported Video Input Resolution

1080p 60/59.94/50
1080p 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50
576i 50
480i 59.94

Video Output

HDMI 1.4x1
SDI loopthrough x1

Audio Input

RCA L/R x1
XLR x2

Encode

H.264/AVC High Profile Level 4.1

Video Bitrate

Each Channel Rec + Stream 30Mbps

Video Rate Mode

CBR

Audio Mode

Stereo/Mono

Audio Bitrate

AAC-LC
Sample rate: 48KHz, 16bit
Configurable bit rate: 128K or 256K or 384K

Streaming Protocols
  • TS over UDP unicast & multicast
  • RTSP over HTTP/TCP/UDP
  • RTMP/RTMPS (Publish)
  • SRT over UDP
  • HLS
Recording File Format

MP4, MOV

Storage

SSD/HDD x1
 (File System: NTFS, FAT, exFAT)

Power Supply

DC 12V 16W

Dimension (LxWxH)

480 x 180 x 44 mm

Weight

2.3kg

Operating Temp. Range

0~40 °C

What's in the Box

1 x NVS-40 main unit
1 x DC 12V Power Adaptor
1 x Thank You Card
2 x 1U Rack Mount Ear
6 x M4 Screws for Rack Mount Ear
1 x 2.5” Removable HDD/SSD Enclosure
4 x Screws for 2.5 Removable HDD/SSD Enclosure
1 x Blank Label
1 x SATA to USB 3.0 Cable

Recommended SSD Drives
  • ORICO SSD TROODON SERIES H100
  • INTEL SSD 5
  • SAMSUNG SSD 860 Pro
  • PNY CS900 SSD
599 000 Ft + ÁFA (br. 760 730 Ft)
Kérdés a termékről
