Video bemeneti formátumok
- SD-SDI: 525i, 625i
- 3G-SDI: 080p60/50, 1080p59.94
- HD-SDI: 1080i60/50, 1080p30/25/24, 1080p29.97, 1080p23.98, 1080i59.94, 720p60/50, 720p59.94
- HDMI: (YUV/RGB): 1080p60/50, 1080p59.94, 1080p30/25/24, 1080p29.97, 1080p23.98, 1080i60/50, 1080i59.94, 720p59.94, 720p60/50, 576p, 480p, VGA, 1600x1200@60Hz, 1400x1050@60Hz, 1366x768@60Hz, 1280x1024@60Hz, 1024x768@60Hz, 800x600@60Hz
Video kimeneti formátumok
- SDI / HDMI (YUV: 4:2:2): 1080p60/50, 1080p59.94, 1080p23.98/29.97/24/25/30, 1080i60/50, 1080i59.94, 720P60/50, 720P59.94, 525i, 625i
Audio formátumok
- SDI embedded Audio: max. 8-CH, PCM 48KHz
- HDMI embedded Audio: max. 8-CH, PCM 96KHz
- sztereo audio bemenet: 2-CH, PCM 48KHz
